Single Rectifier Isolator (GEN 4.1)

• An ideal high current diode
• Charges two batteries or banks from a single charging source
• Allows the discharge of the auxiliary or house batteries independent of the main battery
• Industry-leading ultra-low voltage drop
• Extends battery life by insuring full charging voltage reaches the batteries
• 99.9% efficient at maximum continuous current
• No heat sinks or airflow required
• No de-rating required over full temperature range
• Fully encapsulated solid state design
• Internationally patented MOSFET technology
• Recommended by top battery manufacturers

Now Available

A perfect high current ideal diode, single rectifiers are a single, one-way electrical valve commonly deployed in multi-battery configurations where a single auxiliary battery is dedicated for applications where discharge of the auxiliary battery is to be independent of the primary battery. Don’t confuse POWER-GATE Ideal Diodes with more common, lesser performing silicon and Schottky isolators. POWER-GATE sets the benchmark for ultra-low on-resistance which means devices require no heat sinking and no airflow. Encapsulated in a custom, injection molded Polycarbonate package, single rectifiers are perfectly suited for high vibration, dirty, and moist environments. Available in our Small and Medium enclosures, POWER-GATE is recommended by top battery manufacturers to insure that DC power gets to where it’s needed without the excessive heat and voltage-loss typified by more common, lesser performing silicon and Schottky devices.

Need help configuring a Single Rectifier?  Click Here.

For OEM applications, military and fleet sales, special applications, or general questions call us 858.720.1339.
